STORM AUDIO

Calibration Kit

DIRAC LIVE ROOM-CALIBRATION KIT

Audio

Get Price

Description

StormAudio's Calibration Kit is the full-fat tool every StormAudio integrator brings on site. Built around a calibrated USB measurement microphone and supplied in a custom flight case, it contains everything required to run a complete Dirac Live Room Correction, Bass Control, and Active Room Treatment session on any StormAudio ISP or ISR processor.

The kit ships with a microphone stand and boom, USB and USB-over-CAT5 cabling, and a powered USB/CAT5 extender so the mic can reach the prime listening position from anywhere in the room. The flight case has empty space for additional small equipment so installers can carry a single, organized rig between projects.

Designed to be used with the StormAudio-licensed build of Dirac Live, it produces the measurement data StormAudio's Pro Remote Assisted Calibration (PRAC) service expects — making it the only calibration hardware StormAudio formally endorses for field use.

Download Data Sheet

Learn more about the product specifications

Download

Manifacturer Warranty

Our brands provide full warranty coverage on all listed products.

Tech Support

We provide system support to dealers and installers by offering product guidance, installation and wiring, product troubleshooting, and control programming to ensure optimal performance.

Free Demo

Dealers and installers can book a demo to experience the products in our showroom and learn more.

Training

Dealers and installers receive training on product specs and programming controls to enable effective and convenient distribution. Dealers and installers will be well prepared to meet their clients' needs and expectations.

Specs

Get Price

Specification	Value
Microphone	Calibrated omnidirectional USB measurement microphone
Calibration File	Individual calibration file supplied
Connection	USB + USB-over-CAT5 extender
Stand	Microphone stand with boom included
Cables	USB cables and USB/CAT5 cable & extender included
Carrying	Custom flight case with space for additional gear
Compatible Software	Dirac Live 2.x (StormAudio licensed build)
Supports	Dirac Live, Multi-Subwoofer Bass Control, Active Room Treatment (ART)
Compatible Processors	ISP Elite MK3, ISP Core 16, ISP Evo, ISR Fusion 20 (and legacy ISPs)
Max Channels	Up to 32 channels of calibration
Net Weight	9 kg (19.8 lb)
Gross Weight	12 kg (22 lb)
Box Dimensions	61 x 50 x 25 cm (24 x 19.7 x 9.8 in)
