Specs
Certified Environmental | StingRay Soffit Speaker Kits | Constant Voltage Series |
|---|---|---|
 |  |  |
Stealth’s proprietary FidelityGlass™ flat-front radiating surface ensures the internal components of the StingRay430 are fully isolated from any intrusion of dust or moisture, allowing it to achieve an environmental protection rating of IP-65 as measured to IEC standards (IP-68 for StingRay83, StingRay8, and StingRay 6 Speakers). StingRay subwoofers and speakers can withstand rain, snow, sleet, hail, sun, and dust in temperatures ranging from 0° to 150° F (-17 to 65° C). | Replace ugly conventional under-eaves speakers that deteriorate in the elements with Stealth Acoustics Soffit Kit speakers for high performance, clean aesthetics, and lasting results. The flush-mounted Soffit Kit features a specialized StingRay8 or StingRay83 with an integrated back box, mounting hardware, and a router template for cutting a precise opening for installation. | Stealth’s most popular indoor and outdoor distributed audio speakers are available for commercial audio applications. These Constant Voltage Series (CVS) speakers are compatible with 70/100-volt amplifier systems and have transformer tap values from 5 to 60 watts (depending on the model). Constant voltage speakers are built to suit. Please call Stealth Acoustics for design assistance, custom orders, and availability. |
Specifications
Type | 2-way Full Range | 2-way Full Range | 3-way Full Range | Subwoofer |
|---|---|---|---|---|
Frequency Response | 50Hz to 18kHz | 45hz to 18khz | 40hz to 20khz | 20Hz to 160Hz |
Power Capacity | 120 watts RMS | 160 watts RMS | 160 watts RMS | 400 watts RMS |
Recommended Power | 60 watts (Min) | 80 watts (Min) | 80 watts (Min) | 100 watts (Min) |
Protection | 2 independent self-resetting devices (LF and HF) | 2 independent self-resetting devices (LF and HF) | 3 independent self-resetting devices (LF, MF, and HF) | 4 independent self-resetting devices (LF and HF each channel) |
Sensitivity | 83 dB | 83 dB | 83 dB | 86 dB |
System Impedance | 8Ω nominal | 8Ω nominal | 8Ω nominal | 8Ω nominal |
Polar Dispersion | 170 degrees horizontal & vertical | 170 degrees horizontal & vertical | 170 degrees horizontal & vertical | 360 degrees horizontal & vertical |
HF Driver | One 1-1/8” (30 mm) neodymium motor | One 1-1/8” (30 mm) neodymium motor | One 1” (25 mm) neodymium motor | |
MF Driver | One 1-1/8” (30 mm) neodymium motor | |||
LF Driver | One 1″ (25 mm) voice coil, 6.5″ (165 mm) woofer Ceramic 15 oz. (425 gr) magnet | One 1-1/2″ (38 mm) voice coil, 8″ (203 mm) woofer Ceramic 20 oz. (567 gr) magnet | One 1-1/2″ (38 mm) voice coil, 8″ (203 mm) woofer Ceramic 20 oz. (567 gr) magnet | Eight 1-1/2″ (38 mm) voice coil, 8″ (203 mm) woofer Ceramic 20 oz. (567 gr) magnet |
Crossover | Passive 2-way | Passive 2-way | Passive 3-way | Requires amplifier with low pass filter. 50Hz with 18 dB slope recommended |
Width | 14-7/8” (378 mm) | 20-7/8” (530 mm) | 20-7/8” (530 mm) | 17-1/4” (438 mm) | ||
|---|---|---|---|---|---|---|
Height | 10-7/8” (276 mm) | 14-3/4” (374 mm) | 14-3/4” (374 mm) | 31” (787 mm) | ||
Depth | 3-13/16” (97 mm) | 3-7/8” (98 mm) | 3-7/8” (98 mm) | 17-1/4” (438 mm) | ||
Weight | 12 lbs. (6 kg) – each | 15 lbs. (7 kg) each | 15 lbs. (7 kg) each | 76 lbs. (35 kg) each |
Invisible audio that disappears but leaves the impact
Invisible audio that disappears but leaves the impact
