Stingray 8 Outdoor Loudspeaker

The Stingray 8 is a 2-way full-range outdoor loudspeaker built around an 8 in woofer and a 1-1/8 in neodymium high-frequency driver. Stealth's direct-coupled motor and acoustic-lever architecture drive the FidelityGlass face to produce broad coverage and weather-proof bass for residential and commercial outdoor systems.

2-way passive crossover, 8 in woofer with 1-1/2 in voice coil
45 Hz to 18 kHz frequency response, 160 watts RMS
83 dB sensitivity, 8 ohm nominal impedance
170 degrees horizontal and vertical dispersion
IP-68 environmental rating; two self-resetting protection circuits

The sealed FidelityGlass diaphragm blocks intrusion of moisture and dust, allowing the Stingray 8 to survive rain, snow, sleet, hail, sun and dust between 0 and 150 deg F while maintaining studio-grade audio fidelity in patios, pools, marine environments and landscape installs.

Download Data Sheet

Learn more about the product specifications

Download

Manifacturer Warranty

Our brands provide full warranty coverage on all listed products.

Tech Support

We provide system support to dealers and installers by offering product guidance, installation and wiring, product troubleshooting, and control programming to ensure optimal performance.

Free Demo

Dealers and installers can book a demo to experience the products in our showroom and learn more.

Training

Dealers and installers receive training on product specs and programming controls to enable effective and convenient distribution. Dealers and installers will be well prepared to meet their clients' needs and expectations.

Specs

Get Price

Specification	Value
Type	2-way Full Range
Frequency Response	45Hz to 18kHz
Power Capacity	160 watts RMS
Recommended Power	80 watts (Min)
Protection	2 independent self-resetting devices (LF and HF)
Sensitivity	83 dB
System Impedance	8Ω nominal
Polar Dispersion	170° horizontal & vertical
HF Driver	One 1-1/8" neodymium motor
LF Driver	One 1-1/2" voice coil, 8" woofer
Crossover	Passive 2-way
Width	20-7/8" (530 mm)
Height	14-3/4" (374 mm)
Depth	3-7/8" (98 mm)
Weight	15 lbs. (7 kg)
