Amplifier
Manifacturer Warranty
Our brands provide full warranty coverage on all listed products.
Tech Support
We provide system support to dealers and installers by offering product guidance, installation and wiring, product troubleshooting, and control programming to ensure optimal performance.
Free Demo
Dealers and installers can book a demo to experience the products in our showroom and learn more.
Training
Dealers and installers receive training on product specs and programming controls to enable effective and convenient distribution. Dealers and installers will be well prepared to meet their clients' needs and expectations.
Specs
Specification | Value |
|---|---|
Power Output (8Ω) | 310 watts per channel |
Power Output (4Ω) | 450 watts per channel |
Frequency Response | 20Hz-50kHz (+1/-3dB) |
Total Harmonic Distortion | < 0.05% @ 460W / 4Ω |
Signal-to-Noise Ratio | >105 dB (A-weighted) |
Analog Input Sensitivity | -1dBV for 312.5W output / 8Ω |
Maximum Voltage Gain | 36 dB / 8Ω |
Crosstalk | >85dB |
System Impedance | 8Ω nominal, 4Ω minimum |
Rack Space | 2 RU (3-1/2") |
Width | 19" (482 mm) |
Depth | 15-3/4" (400 mm) |
Height | 3-1/2" (89 mm) |
Shipping Weight | 38 lbs (17.2 kg) |
Heat Dissipation | 849 BTU/Hr |
