Specs
Years of R&D birthed a new loudspeaker technology system integrators are now using to solve room problems old school loudspeakers worsen.
The resulting DML500 eschews pumping focused air pressure waves that point-source cone loudspeakers employ to create ear-fatiguing sound.
Instead, non-destructive waves emerge wide and diffuse to more gently bathe the ear in pleasing, super-intelligible sound over almost eight octaves.
Even kinder on the ears: the DML500 measures 6dB lower despite perceived loudness equal to point-source.
Especially noticeable in highly reverberant spaces, DML sound waves provide non-destructive room interactions, so free of room echo and comb filtering that one customer referred to the intelligibility improvement over their old church system as “mind boggling.”
Floor-to-balcony, stereo-stable imaging in every seat is another performance “wow,” making the DML500 the top choice for immersive audio
Superb power handling plus 165° conical coverage allowed an American airport to replace 104 traditional speakers with six DML500 loudspeakers
Unmatched placement flexibility also optimizes aesthetic choices and quicker installations.
Rugged construction includes a powder coated die cast aluminum enclosure with multiple mounting points (200×200 VESA adapter is available for purchase separately)
Accessories
If attachment to a VESA mount accessory with specific 200mm x 200mm pattern is required, we offer a VESA adapter (sold separately). Other mounting options are described in our Rigging Guide.
Recommended filtering/crossover
The following are the initial recommended acoustic filters as implemented in all DML accoustic measurements. They also represent an EQ starting point for all field applications.
High Pass – Butterworth 4th order (24 dB) @ 90Hz
Peaking Filter – 95Hz / Q of 3 /Gain of 3 dB
Peaking Filter – 265Hz / Q of 0.7 / Gain of -4 dB
High Shelving Filter – 400Hz / Q of 0.5 / Gain of 2 dB
Peaking Filter – 2800Hz / Q of 0.9 / Gain of -3 dB
DML500 Specifications
Specification | Details |
|---|---|
Frequency range / -10dB | 75Hz–20kHz |
Frequency response / ±6dB | 85Hz–20kHz |
Horizontal / vertical coverage | 165° |
System sensitivity | 92dB SPL |
Rated maximum SPL | 123dB |
System nominal impedance | 8 Ohms |
Power handling | Continuous: 200W |
Suggested high pass filter | 90Hz Butterworth 2nd order |
Drivers
Specification | Details |
|---|---|
Transducer type | FlatPanel transducer |
DML exciters | 4 × DML exciter |
Voice coil diameter | 32mm |
Voice coil winding wire | Copper-clad aluminum |
Suspension design | Standard spider |
Diaphragm design | Bending wave modal |
Design principle | Bending wave modal |
Radiator surface area | 400 × 575mm |
Material | Carbon fiber honeycomb |
Input Connection
Specification | Details |
|---|---|
Input connector | Neutrik Speakon® NL4 |
Input wiring | +1 / -1 |
Loop out wiring | +2 / -2 |
Physical
Specification | Details |
|---|---|
Outer dimensions / H × W × D | 21.6″ × 31.5″ × 3.5″ |
Outer dimensions / metric | 550mm × 800mm × 90mm |
Outer frame | 4 × MB |
Outer frame dimensions | 15.5″ × 19.13″ / 395mm × 486.5mm |
Rear grill | 4 × MB |
Rear grill dimensions | 9.13″ × 7.95″ / 292mm × 202mm |
Weight | 44 lbs / 20.3kg |
Shipping dimensions | 27″ × 37″ × 8″ |
Shipping dimensions / metric | 650mm × 800mm × 250mm |
Shipping weight | 51 lbs / 23.2kg |
