Specs
Specification | Value |
|---|---|
Configuration | 2-way dual 12-inch self-powered vented direct-radiating full-range with rotatable 80 x 60 degree constant-directivity horn |
LF drivers | 2 x 12-inch neodymium woofers, 3.5-inch voice coils |
HF driver | 1 x 3-inch compression driver, 1.4-inch exit, on rotatable horn |
Amplifier | 3,200W Class-D 2-channel (2,400W LF / 800W HF) |
Frequency response | 50Hz - 18,000Hz (+/-3dB) |
Maximum SPL | 136dB sustained / 142dB peak (1m, half-space) |
Coverage | 80 x 60 degrees (rotatable) |
Processing | 96kHz DSP with 8 pushbutton presets |
Inputs | XLR-F signal in; Neutrik powerCON TRUE1 (power) |
Power | 100-240V AC, 50/60Hz; 4.6A @ 120V nominal |
Dimensions (H x W x D) | 47.75 x 14.3 x 17.75 in |
Weight | 99 lb (45 kg) |
Sound systems built for extreme bass output and uncompromising sonic power
Sound systems built for extreme bass output and uncompromising sonic power
