IP-JP4-RX-10

1Gb 4K HDR Decoder & Video Wall Processor

Video

Get Price

1Gb 4K60 HDR PoE Decoder & Video Wall Processor

Processes landscape and portrait video walls upto 16x16
Onboard 4K/2K scaling allowing support for legacy displays
Ultra-low latency including Genlock synchronization between decoders
Enhanced compatibility mode tailored for video conferencing hubs, laptops and commercial displays
ARC/eARC Capture & Routing
Connected device control via IR, RS-232-CEC

Download Data Sheet

Learn more about the product specifications

Download

Manifacturer Warranty

Our brands provide full warranty coverage on all listed products.

Tech Support

We provide system support to dealers and installers by offering product guidance, installation and wiring, product troubleshooting, and control programming to ensure optimal performance.

Free Demo

Dealers and installers can book a demo to experience the products in our showroom and learn more.

Training

Dealers and installers receive training on product specs and programming controls to enable effective and convenient distribution. Dealers and installers will be well prepared to meet their clients' needs and expectations.

Specs

Get Price

Specification	Detail
Supports HDMI2	0b 18Gb HDMI input signal.
Compliance up to HDCP2	2
Max Video Transmission 3840x2160 30fps 4	2:0 8bit
Audio \| Video	Video signal over LAN not exceeding 850Mbs
Supports 4K 30Hz 4	2:0 8bit HDR
IP Preview (RTSP) Main Output 1920x1080 30fps + LPCM 2	0 audio
Audio \| Video	IP Preview Sub Output 960x580 30fps
Enhanced compatibility mode ideal conference hubs	laptop & commercial display integration.
HDMI Loop Out (TX) 3840x2160 60fps 8b 4	4:4
HDR Compatible including HDR10	HLG, HDR10+ & Dolby Vision
Audio \| Video	Scaler capable of 4K to 2K
Audio \| Video	End to Latency = 1 video frame
LPCM 2	0/5.1/7.1CH, Dolby Digital/Plus/EX, Dolby True HD, Dolby Atmos DTS, DTS-96/24, DTS-EX DSD, DTS High Res, DTS-HD Master, DTS:X
Audio \| Video	Audio connectivity from HDMI or Analog connectivity.
Audio \| Video	Ability to embed additional audio source to HDMI signal via encoder.
IP	JP4-CL-10 (Secure IP Terminal/Controller)
IP	SW-24P-10 (Network Switch)
IP	SW-48P-10 (Network Switch)
TS	13-10 (Touch Panel)
Not compatible with IP	JP4-60 (DNT) series products.
