Decoder

NETVIO TX Dante AV-A encoder with ports.

Device ports: DC 12V, AV LAN, HDMI OUT, HDMI IN, S/P DIF OUT, Audio IN/OUT, RS-232, IR IN/OUT

NETVIO TX Dante AV-A with multiple ports.

Netvio Dante AV-A TX and RX units with HDMI and audio ports.

NETVIO

IP-JP4-60-DNT-TX-10

1Gb 4K60 HDR, 2K30 Multi-Stream Dante AV-A Encoder

Video

Get Price

4K60 (4:4:4) AVoIP Dual Stream Encoder over 1GbE up to 100m (328ft) with Dante AV-A

Newest iteration of Dante compatible video solutions.
Adds two channels of Dante audio that are interoperable with any Dante-enabled device.
Device monitoring through Dante Director & Domain Manager.
Latest Gen2 Dual 1Gb 4K (4:4:4) HDR, 2K30 PoE Encoder
Superior picture quality with pixel-for-pixel quality,
4K HDR video encoding not surpassing 850Mbs
ContentPlus+ 2K30 Low Bandwidth Real-time-stream-protocol (RTSP) including stereo audio
Fast Switching with Genlock Synchronicity.

Download Data Sheet

Learn more about the product specifications

Download

Manifacturer Warranty

Our brands provide full warranty coverage on all listed products.

Tech Support

We provide system support to dealers and installers by offering product guidance, installation and wiring, product troubleshooting, and control programming to ensure optimal performance.

Free Demo

Dealers and installers can book a demo to experience the products in our showroom and learn more.

Training

Dealers and installers receive training on product specs and programming controls to enable effective and convenient distribution. Dealers and installers will be well prepared to meet their clients' needs and expectations.

Specs

Get Price

Product Overview

Specification	Details
Model	IP-JP4-60-DNT
Category	Audio / Video over IP device
Product type	Encoder or decoder device

Audio / Video

Specification	Details
HDMI support	HDMI 2.0b, 18Gb HDMI input signal
HDCP support	HDCP 2.2, compatible with HDCP 2.3 devices
Maximum video transmission	3840 × 2160, 60fps, 4:4:4, 8-bit
Video over LAN bitrate	Not exceeding 850Mbps
HDR support	4K60, 4:2:2, 10-bit
Dante audio	2 × 2 Dante audio channels
IP preview main output	1920 × 1080, 30fps + LPCM 2.0 audio
IP preview sub output	960 × 580, 30fps
Compatibility mode	Enhanced compatibility mode for conference hubs, laptops and commercial display integration
HDMI loop out / TX	3840 × 2160, 60fps, 8-bit, 4:4:4
HDR compatibility	HDR10, HLG, HDR10+ and Dolby Vision
Scaler	4K to 2K capable
End-to-end latency	Less than 1 video frame
Audio formats	LPCM 2.0 / 5.1 / 7.1CH, Dolby Digital / Plus / EX, Dolby TrueHD, Dolby Atmos, DTS, DTS-96/24, DTS-EX, DSD, DTS High Res, DTS-HD Master, DTS:X
Audio connectivity	Multiple analog and digital audio options
ARC / eARC	Supports ARC/eARC capture and routing
Audio embedding	Ability to embed an additional audio source to HDMI signal via encoder

Software & Control / Netvio Mode

Specification	Details
Configuration software	Compatible with Netvio360
Netvio360 functions	Discovery, configuration, security, management and routing
Control signal routing	Independent routing of IR, RS-232 and CEC
Control system drivers	Crestron, Control4, Savant, RTI, ELAN and Q-SYS
Onboard control app	NetvioGo-Control
App license	License-free
App purpose	Alternative to traditional control systems for streamlined AV control
Onboard ports	IR and RS-232
Signal routing	Via control system

Dante Software / AV-A Mode

Specification	Details
Dante Controller	Compatible
Dante Director	Compatible
Dante Domain Manager	Compatible

Approved Network Switches

Brand / Series	Details
Netvio	IP-SW Series
Netgear	AV Line
Cisco	Catalyst, SG and CBS Series
Draytek	P Series
Araknis	210 and 310 Series
Cambium	EX2000 and EX3000 Series
Other switches	Compatible with additional Layer 2 managed switches

Electrical & Mechanical

Specification	Details
Warranty	5-year product warranty
Product approvals	CE, UKCA, FCC, RoHS
Product dimensions	W 205mm × D 100mm × H 22mm
Product dimensions / imperial	W 8.07″ × D 3.94″ × H 0.87″
Package dimensions	W 255mm × D 157mm × H 77mm
Package dimensions / imperial	W 10.04″ × D 6.18″ × H 3.03″
Unit weight	500g
Package weight	900g
Power	IEEE 802.3af
Power consumption	10W max per device
PSU	Not provided
Operating temperature	32°F to 104°F / -20°C to 60°C
Storage temperature	-4°F to 140°F / -20°C to 60°C
BTU	30 BTU/hr nominal

Compatible Products

Product	Details
IP-JP4-CL-10	Secure IP Terminal / Controller
IP-RK-10	Rack
IP-SW-24P-10	Network Switch
IP-SW-48P-10	Network Switch
TS-13-10	Touch Panel
TS-10-10	Replacement / moving to TS-10-10
DNT Series Devices	Compatible
JP4 Devices	Not compatible

Box Contents

Item	Details
Device	Encoder or decoder device
Mounting accessories	Wall mounting brackets
Connectors	Phoenix connectors for RS-232 and audio
IR accessories	IR TX and IR RX accessories
