Specs
Network & Power
Specification | Details |
|---|---|
Network | 1 × RJ45 jack |
Ethernet | 100 / 1000 Ethernet |
DHCP | Enabled by default |
Power | AC 100–120V / 220–240V, 50/60Hz |
Power consumption | 1000W |
Trigger Outputs
Specification | Details |
|---|---|
Trigger outputs | 3.5mm mono |
Output types | Zone trigger / system trigger outputs |
Pinout | Tip = signal, sleeve = ground |
Output | +12Vdc |
Current limit | 100mA |
Line Level Audio Outputs
Specification | Details |
|---|---|
Line level audio outputs | 2 stereo / 4 mono analog RCA pre-amp outputs |
Configuration | Left, right, mono or subwoofer |
Line level output | Fixed or variable |
Fixed output | 0dB nominal gain |
Variable output | -50dB to +0dB |
Adjustment steps | 0.5dB per step |
Output type | Unbalanced |
Output impedance | 470Ω |
Amplifier Outputs
Specification | Details |
|---|---|
Amplifier outputs | 4 stereo / 8 mono amplifier outputs |
Configuration | Left, right or mono |
Output power @ 8Ω | 80W |
Output power @ 4Ω | 100W |
THD | <0.05% @ 1kHz |
Frequency response | 20Hz–20kHz, +0.5dB / -0.5dB |
Crosstalk | >60dB @ 1kHz / 1W |
Signal to noise | >100dB |
Lip Sync Delay
Specification | Details |
|---|---|
Lip sync delay | Individual lip sync delay for each speaker and preamp zone |
Delay time | 0–400ms |
Adjustment | 10ms increments |
Tone Control
Specification | Details |
|---|---|
Tone control | Individual tone control for each zone |
Equalizer | Five-band equalizer |
Loudness | On / off |
Filters | High / low pass |
Crossover points | Adjustable |
Temperature & Humidity
Specification | Details |
|---|---|
Operating temperature | +5°C to +45°C / +41°F to +113°F |
Operating humidity | 0–90% non-condensing |
Storage temperature | 0°C to +60°C / 32°F to +140°F |
Dimensions & Weight
Specification | Details |
|---|---|
Dimensions with feet | 17″ D × 17″ W × 4″ H |
Dimensions with feet / metric | 431.8 D × 431.8 W × 101.6 H mm |
Dimensions without feet | 17″ D × 17″ W × 3.5″ H |
Dimensions without feet / metric | 431.8 D × 431.8 W × 88.9 H mm |
Weight | 21.35 lbs / 9.68kg |
