Controller
Manifacturer Warranty
Our brands provide full warranty coverage on all listed products.
Tech Support
We provide system support to dealers and installers by offering product guidance, installation and wiring, product troubleshooting, and control programming to ensure optimal performance.
Free Demo
Dealers and installers can book a demo to experience the products in our showroom and learn more.
Training
Dealers and installers receive training on product specs and programming controls to enable effective and convenient distribution. Dealers and installers will be well prepared to meet their clients' needs and expectations.
Specs
Specification | Value |
|---|---|
RS-232 | (8) RJ-45 ports, null modem configurable |
RS-485 | (2) RJ-45 ports |
IR Output | (12) 3.5mm ports (Mono), -12V DC |
Signal Input | (4) Terminal Block Connectors 3-pin |
Relay | (6) Terminal Block Connectors 3-pin |
HDMI | (1) HDMI 2.0 for 4K 60Hz output with HDCP 1.4/2.2 support |
USB | (1) 3.0 USB / (1) 2.0 USB |
RCA Audio | (2) RJ-45 port |
Wi-Fi | 2.4 / 5GHz 802.11 b/g/n/ac, frequencies 5745-5825 and 2400-2483.5 |
Z-Wave | Yes |
Software Compatibility | Requires Core Module 8.9 or above |
Updates | Managed by Management Cloud |
Power | 120/240VAC Input 12VDC 1A output |
PoE | IEEE 802.3af (802.3at Type1) |
Operating Temperature | 0° to 40°C |
Operating Humidity | 90% Maximum (Non-Condensing) |
Mounting | Free standing, Rack mount |
Product Dimensions | With feet: 17" W x 2.25" H x 14" D (431.8 x 57.2 x 355.6 mm); Without feet (rack brackets): 19" W x 1.75" H x 14" D (482.6 x 44.45 x 355.6 mm) |
Weight | 8 lbs 11 oz / 3.95 kg |
