Specs
Channels | 8 |
|---|---|
Power per Channel (2Ω) | 80W |
Power per Channel (4Ω) | 160W |
Power per Channel (8Ω) | 160W |
Power per Channel (70V / 100V) | 160W |
Analog Inputs | 8 balanced, selectable 26 dB / 34 dB sensitivity |
Network Audio | 8 × 8 Dante at 96 kHz or 48 kHz; AES67 via Dante Controller |
Network | Built-in Wi-Fi AP, existing Wi-Fi, or FAST Ethernet (Cat5/Cat6) |
DSP | Analog Devices Sigma 96kHz, 32-bit core; 8-band parametric EQ/channel; up to 48 dB/oct crossovers |
Control | LEA CONNECT Cloud, Web Browser UI, 3rd-party API |
Dimensions | 14.25" L × 19" W × 1U (362 × 482 mm) |
Weight | 13.55 lbs / 6.15 kg |
Amplifiers for commercial AV systems with network architecture and remote access capabilities
