Description
Passive line array module, based on dual 8’’ woofers with 1,4’’ throat HF driver. Compact size, yet significant power and performance, numerous installation options – it’s what makes MAG WASP-8 an ultimate solution for different applications, from corporate parties to mid-sized concerts.
Product description:
Passive line array module
Main features:
600 W nominal power
2 x 8” woofers with 2,5” voice coil
1.5” HF driver with 2,8” voice coil
141 dB Max SPL
Integrated flying hardware
Type | Passive line array module |
Acoustical & Electrical data | |
Frequency response (-10dB) | 70 - 20000 Hz |
Max SPL 1 | 141 dB (single cabinet) |
Sensitivity (1W/1m) | 98 dB Low |
Sensitivity (1W/1m) (in detail) | 98 dB Low / 110 dB High |
LF Driver | 2 x 8", 2,5" VC |
HF Driver | 1,5", 2,8" VC |
Nominal Coverage Angle (Horizontal × Vertical) | 100° x Depends on the number of cabinets |
Impedance | 16 Ohm LF, 16 Ohm HF |
Nominal power 2 | 600 W Low |
Nominal power (in detail) 2 | 600 W Low / 100 W High |
Connectors | 2 x Neutrik Speakon |
Connections and physical data | |
Dimensions (W x H x D) | 622 x 279 x 422 mm |
Net weight | 22 kg |
Shipping weight | 25 kg |
Mounting | Integrated mounting hardware; 0° - 10° splay angle |
Enclosure material | Plywood; wear-resistant paint |
Speaker protection | Steel grill, synthetic acoustically transparent cloth |
1 pink noise, filtered according to AES 2 - 2012, crest factor 12 dB
2 based on transducer power measured according to AES 2 - 2012
